Legion-LCM

Multi-Modal LCM
CATEGORIES Oilfield / Cementing Technologies, Drilling Fluids Technologies / Lost Circulation
JUMP TO

GENERAL DESCRIPTION

Riteks Legion-LCM - Multi-Modal LCM is a highly-efficient, multi-modal loss circulation material engineered to combat downhole losses across a broad range of applications. Riteks Legion-LCM - Multi-Modal LCM is an effective bridging and sealing agent when used in conventional spacers and cement slurries, but added performance is witnessed when coupled with one of Riteks RiSeal™ Sealing Spacers. This specially formulated all-in-one single sack solution minimizes operational complexity, saves time, and provides superior down hole performance.
Other Names & Identifiers
  • Single-Blend PSD LCM
  • Engineered Granular LCM
  • One-Sack Bridging Material
  • All-In-One Bridging Package
  • Graded-Particle LCM
  • Wellbore-Strengthening PSD Blend
  • Granular Multi-Size LCM
  • Unified PSD Bridging Agent
  • Composite Particle-Size LCM
  • Pre-Engineered Particle LCM
  • Single-Component Loss-Control Blend
  • Multi-Modal Particle LCM
  • Formation-Bridging Granules
  • Universal Bridging LCM

APPLICATIONS & BENEFITS

APPLICATIONS

APPLICATIONS & BENEFITS
Riteks Legion-LCM - Multi-Modal LCM is designed for use in both preventative and remedial loss circulation applications during drilling and cementing operations. Riteks Legion-LCM - Multi-Modal LCM is Riteks' most effective plugger to date. It can plug a 3 mm slot with just 10 to 15 lb/bbl loading depending on carrying fluid. Recommended loadings are 0.5 to 3 lb/bbl for loss prevention to seepage type losses, 4 to 7 lb/bbl for partial losses, and 8 to 15 lb/bbl for severe or total losses. To ensure safe passage through wellbore restrictions, Riteks Legion-LCM - Multi-Modal LCM concentrations should be adjusted accordingly. The carrying fluid must maintain a rheological profile that supports dynamic and static suspension, considering interactions with surrounding fluids and thermal changes to prevent settling and flow disruptions.

FEATURES & ADVANTAGES

APPLICATIONS & BENEFITS
  • Wide array of particle sizes capable of sealing slotted openings up to 3000 microns
  • Excellent low pressure and high pressure LCM
  • Capable of bridging and sealing
  • Pre-blended, single-bag format reduces bulk plant preparation time
  • Very compatible with water-based and oil-based fluid systems
  • Helps to ensure proper top of cement
  • Helps to prevent leak-off, fallback, and improves barrier integrity
  • When coupled with Riteks RiSeal™ Spacers, can eliminate the need for a DV Tool and cure severe losses

Technical Specifications

PACKAGING
50lb Bags
GENERAL PHYSICAL PROPERTIES
Appearance
Multi-Modal, Particulates & Fibers
Specific Gravity
1.36
Absolute Volume
0.0881
Bulk Density
36
Moisture %
0
